Test Station | Four stations, each completely independent (customizable) | ||||
Inspiratory time | 0 ~ 10 S adjustable | ||||
Counter | 0 ~ 999999 settable | ||||
Suction Mode | Piston type | ||||
Power source | Stepping motor + linear slide rail | ||||
Display and control mode | Color touch screen + PLC | ||||
Other function | It can directly test the pneumatic cigarette rod, and can also be equipped with a pressing device to test the button electronic atomizer. | ||||
Power source | 1∮、AC220V、5A | ||||
Volume (W × D × H) | Approx. 1050 X 550 X 580 mm | ||||
Weight | Approx. 115 kg | ||||
Inhalation Stop Time | 0 ~ 100S adjustable | ||||
Suction capacity | 0~150ml | ||||
Suction volume accuracy | ±1% |
